Racked-Mounted Storage Batteries
- Supports parallel use with multiple units and features a quick-connect plug for effortless expansion
- Natural cooling reduces the power consumption of the entire model
- A-grade battery cells are meticulously selected to ensure a 10-year service life
- The modular design is easy to install and easy to maintain
- Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit
- Safety handle, made of stainless steel
- Flexible module stacking with connectors for easy disassembly and setup
- Large capacity, high circulation, safe and stable
| Item | Specifications |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Energy | 5.12KWh |
| Working voltage | 40 ～58.4V |
| Charge Voltage | 58.4V |
| Standrad Charge Current | 20A |
| Max Charge Current | 100A |
| Discharge Cut-off Voltage | 40V |
| Standard Discharge Current | 20A |
| Max Discharge Current | 100A |
| Cell Model | LF100LA 3.2V/100Ah |
| Housing Material | Cold Rolled Steel Plate |
| Dimensions | 440*480*133±2mm |
| Weight | ≈ 48kg |
