Powerwall Storage Batteries
- Supports parallel use with multiple units and features a quick-connect plug for effortless expansion
- Natural cooling reduces the power consumption of the entire model
- A-grade battery cells are meticulously selected to ensure a 10-year service life
- The modular design is easy to install and easy to maintain
- Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit
- The touchscreen design enhances user convenience and ease of operation
- The unique wall-mounted design is easy to move and takes up little space
- Large capacity, high circulation, safe and stable
| Item | Specifications |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Energy | 10240Wh |
| Working Voltage | 40~58.4V |
| Charge Voltage | 58.4V |
| Standrad Charge Current | 40A |
| Max Charge Current | 100A |
| Discharge Cut-off Voltage | 40V |
| Standard Discharge Current | 40A |
| Max Discharge Current | 100A |
| Cell Model | LFP 50160116 3.2V 100Ah |
| Housing Material | Cold Rolled Steel Plate |
| Dimensions | 725*550*162±2mm |
| Weight | ≈83kg |
